NK.MB030

PERISTALTIC PUMPS - DIGITAL FOR BRIGHTNER

10÷100% VARIABLE SPEED
SUITABLE FOR HIGH VISCOUS LIQUIDS
LONG LIFE HOSE
QUICK WALL MOUNTING
IP65 IN POLYPROPYLENE BOX fire and acid proof
ON/OFF SWITCH completely protected
POSSIBILITY OF CUSTOMIZATION ON THE PUMP HEAD (UPON REQUEST)
RINSE AND LOAD SPEED ADJUSTABLE ON-LINE
FUNCTIONAL STOP
PARAMETER SETTING MENU PROTECTED BY PASSWORD (0÷999)
CONTROL OF THE MOTOR AND OF THE INITIAL START UP WITH VISUALIZATION IN CASE OF OVERLOAD ON THE MOTOR AND MANAGEMENT OF STARTING ATTEMPTS
3 WAY SWITCH FOR STAND BY AND MANUAL PRIMING COMPLETELY PROTECTED
LEVEL SWITCH INPUT (OPTIONAL)
4 DIGIT DISPLAY WITH ALARM AND WORKING STATE VISUALIZATION
BUBBLE BUTTON FOR PROG/DOWN AND UP
THE PUMPS IS ABLE TO RECOGNIZE THE FIRST LOAD AND ACID PROOF
power cable for connection with rinse solenoid
the programming allows to set the dosing time and speed for the charge and rinse

TECHNICAL FEATURES

FLOW RATES PRESSURES POWER SUPPLY REVOLUTION DISPLAC. FITTINGS DIMENSIONS WEIGHT
variable 0÷1 lt/h 3 bar 100÷240 Vac, 24 Vac 0,7 ml Ø4x6 mm 112x90x90 mm 0,6 kg
